| Test Range: | 0.8～10000 |
|---|---|
| Testable Objects & Functions: | Supports Three-phase Transformer, Single-phase Transformer, PT, CT, Z-type Transformer; Tests Transformation Ratio, Vector Group And Polarity; Supports CT Polarity Ratio Test And Single-phase Angle Difference Test |
| Alarm Function: | High & Low Voltage Reverse Connection Alarm, Output Short Circuit Alarm |
| Model: | The HZD1601 |
|---|---|
| Hv Voltage: | AC DC 50kV-300kV Customizable |
| Voltage Range: | Up To 1000 KV |
| Ratio Measurement Accuracy: | ≤200: ±(Reading×0.1%+2 Digits)200～500: ±(Reading×0.2%+2 Digits)＞500: ±(Reading×0.3%+2 Digits) |
|---|---|
| Ratio Resolution: | 0.9～9.9999: 0.000110～99.999: 0.001100～999.99: 0.011000～1999.9: 0.1Above 2000: 0.1 |
| Max Tap Position: | Maximum 99 Tap Positions |
| Resolution: | 0.1μΩ |
|---|---|
| Measuring Resistance Rang: | Multi-range Matching Corresponding Output Current |
| Measurement Accuracy: | 0.2% |
| Test Frequency: | 0.1Hz (Optional 0.05Hz / 0.01Hz) |
|---|---|
| Tan Delta Test Voltage Range: | VLF-34kV: 1kV ~ 24kV RMS VLF-45kV: 1kV ~ 31.8kV RMS |
| Max. Cable Capacitance (0.1Hz): | VLF-34kV: 0.5μF @24kVrms VLF-45kV: 0.5μF @31.8kVrms |
| Switch Channels: | 8 Input Channels, 4 Output Pairs |
|---|---|
| Timing Measurement Range: | 0.1ms – 9999s |
| AC Phase Current Output: | 0–40A, 3-phase Parallel Max 120A |
| Test Range: | 0.8～10000 |
|---|---|
| Testable Objects & Functions: | Supports Three-phase Transformer, Single-phase Transformer, PT, CT, Z-type Transformer; Tests Transformation Ratio, Vector Group And Polarity; Supports CT Polarity Ratio Test And Single-phase Angle Difference Test |
| Alarm Function: | High & Low Voltage Reverse Connection Alarm, Output Short Circuit Alarm |
| Model: | The HZD1601 |
|---|---|
| Hv Voltage: | AC DC 50kV-300kV Customizable |
| Voltage Range: | Up To 1000 KV |
| Ratio Measurement Accuracy: | ≤200: ±(Reading×0.1%+2 Digits)200～500: ±(Reading×0.2%+2 Digits)＞500: ±(Reading×0.3%+2 Digits) |
|---|---|
| Ratio Resolution: | 0.9～9.9999: 0.000110～99.999: 0.001100～999.99: 0.011000～1999.9: 0.1Above 2000: 0.1 |
| Max Tap Position: | Maximum 99 Tap Positions |
| Resolution: | 0.1μΩ |
|---|---|
| Measuring Resistance Rang: | Multi-range Matching Corresponding Output Current |
| Measurement Accuracy: | 0.2% |
| Output Frequency: | 0.1Hz, 0.05Hz, 0.02Hz |
|---|---|
| Waveform Distortion: | ≤5% |
| Load Capacity: | 0.1Hz≤1.1μF, 0.05Hz≤2.2μF, 0.02Hz≤5.5μF |
| Switch Channels: | 8 Input Channels, 4 Output Pairs |
|---|---|
| Timing Measurement Range: | 0.1ms – 9999s |
| AC Phase Current Output: | 0–40A, 3-phase Parallel Max 120A |
