Transformer Turns Ratio Tester for Power Transformer Testing
Product Introduction
The Transformer Turns Ratio Tester is a professional testing instrument designed for transformer ratio measurement during commissioning, maintenance, and preventive inspection.
Compared with traditional ratio bridge testing methods, this instrument provides a more convenient and efficient solution with a large color LCD display, intuitive operation interface, and automatic three-phase ratio testing capability.
The tester adopts three-phase digital sine wave inverter technology, providing fast testing speed, high measurement accuracy, and stable performance.
It supports testing of power transformers, distribution transformers, potential transformers (PT), current transformers (CT), and Z-type transformers, making it suitable for power utilities, substations, transformer manufacturers, and electrical testing organizations.
Application Areas
The Transformer Turns Ratio Tester is widely used in:
| Industry |
Application |
| Power Utilities |
Transformer commissioning, maintenance, and preventive testing |
| Substations |
Transformer inspection and condition assessment |
| Power Plants |
Electrical equipment testing and maintenance |
| Transformer Manufacturers |
Factory testing and quality control |
| Electrical Contractors |
Transformer installation and commissioning |
| Testing Laboratories |
Professional transformer ratio testing |
Technical Parameters
| Parameter |
Specification |
| Measurement Range |
0.8～10000 |
| Accuracy ≤1000 |
±(Reading*0.1%+2 digits) |
| Accuracy 1000-3000 |
±(Reading*0.2%+2 digits) |
| Accuracy >3000 |
±(Reading*0.3%+2 digits) |
| Resolution |
0.0001～1 |
| Test Type |
Three-phase / Single-phase / Z-type |
| Supported Testing |
Transformer, PT, CT ratio and polarity testing |
| Maximum Tap Position |
99 taps |
| Display |
7.0 inch TFT color LCD |
| Data Storage |
Up to 100 test records |
| Communication Interface |
USB data transfer |
| Power Supply |
Built-in lithium battery, AC100-240V adapter |
| Weight |
7.5kg (Complete set), 1.9kg (Main unit) |
| Dimension |
280mm * 180mm * 80mm |
| Operating Temperature |
-10℃～50℃ |
| Relative Humidity |
≤90%, non-condensing |
Key Features
| Feature |
Description |
| High Accuracy Ratio Measurement |
Provides accurate transformer ratio measurement with maximum range up to 10000 |
| Three-phase Automatic Testing |
Completes three-phase transformer ratio testing efficiently with one connection |
| Multiple Transformer Testing |
Supports power transformers, PT, CT, and Z-type transformer testing |
| CT Ratio & Polarity Testing |
Provides CT ratio and polarity measurement function |
| Intelligent Operation |
Large color LCD display with simple menu operation |
| Wide Tap Testing Range |
Supports transformer tap positions up to 99 levels |
| Safety Protection Function |
Provides high/low voltage reverse connection warning and output short circuit warning |
| Data Storage & Printing |
Stores test results and supports USB transfer and thermal printing |
| Portable Design |
Lightweight structure suitable for field testing |
Product Advantages
Efficient Transformer Testing Solution
The instrument simplifies traditional transformer ratio testing procedures and improves testing efficiency through automatic measurement and direct result display.
Professional Electrical Testing Equipment Manufacturer
Developed and manufactured by Wuhan Hongzhi Gaocetest Electrical Technology Co., Ltd., with extensive experience in electrical testing equipment research and production.
Reliable Performance for Field Applications
- High measurement accuracy
- Stable testing output
- Fast testing speed
- Easy operation interface
- Suitable for different transformer testing environments
Factory Direct Supply & Custom Solutions
We provide:
- Professional electrical testing solutions
- OEM customization service
- Technical consultation
- Complete after-sales support
FAQ
Q1: What is a transformer turns ratio tester used for?
A transformer turns ratio tester is used to measure transformer ratio, polarity, and connection conditions to verify transformer performance during installation and maintenance.
Q2: Which equipment can be tested with this instrument?
It supports:
- Power transformers
- Distribution transformers
- Potential transformers (PT)
- Current transformers (CT)
- Z-type transformers
Q3: What is the maximum measurement range?
The maximum measurement range of this transformer ratio tester can reach 10000.
Q4: Can test data be saved and printed?
Yes. The instrument supports internal data storage, USB data transfer, and thermal printer output.
Q5: Can it be customized for different applications?
Yes. Customized solutions can be provided according to different testing requirements.
